22/12/2024

Cable tie inside serrated, 388.0x7.6mm, ∅3.0-100mm, black, 50pcs.
Art.-No. 111-02121 | T120R-PP-BK |  Details

The Allrounder: T-Series cable ties can be used for almost any type of application.

    • Polypropylene cable ties for higher chemical resistance
    • Can withstand continuous operating temperatures up to 115 °C
    • Different sizes available in black and natural color
    • Due to its low-density PP cable ties can float on water
    • Less hydroscopic material, almost no water absorption
    Show more
    Downloads Datasheet e-Learning
    Application T-Series cable ties made from Polypropylene (PP) are less hydroscopic and offer a higher chemical resistance and temperature range compared to a standard Polyamide 6.6 (PA66) material. Cable ties from Polypropylene can withstand continuous operating temperatures up to +115 °C. These cable ties are used to bundle and secure cables, pipes and/or hoses.
    Colour Black (BK)
    Description CABLE TIES INSULOK 388 x 7.8mm POLYPROP
    Identification Plate Position none
    Material Polypropylene (PP)
    PART DESCRIPTION T120R-PP-BK
    Pack Cont. 50pcs.
    Package Content packed in bag
    Part No. T120RBKP
    Product Family T-Series in PP
    Product Group Cable Ties for higher chemical resistance for temperatures up to +115°C in Polypropylene
    Releasable Closure (Yes/No) No
    Tie Closure plastic pawl
    Type T120R
    Variant Inside Serrated
    Bundle Diameter max (metric) 100mm
    Bundle ∅ min. 3.0mm
    Cable Tie Head Length (metric) 10.5mm
    Cable Tie Head Width (metric) 12.65mm
    Height (H) 7.35mm
    Length (L) 388.0mm
    Min.Tensile Strength 270N
    Strap Width max. (G) 0.50"
    Thickness (T) 1.9mm
    Width (W) 7.6mm
    Flammability UL 94 HB
    Halogen-free Yes
    Operating Temperature -40 °C to +115 °C
    ROHS compliant Yes
    Specifications
    UV-Stabilised No
    GTIN-13 / EAN 6005242004513
    UNSPSC Key 39121703
