Gel cable joint, 8.0-10mm, 3 x 0.5mm² to 3 x 1.5mm², L=38mm, Polyamide 6.6 V0 (PA66V0)/Silicone (SI), black
Art.-No. 435-01653 | Relilight V31.5U1-PA66V0/SI-BK |  Details

Gel cable joint Relilight V 31.5 U1.

    • Two- part, black moulding shells
    • Flame-retardant shell moulds according to UL94 V0
    • Safety class IP68
    • Strain relief integrated in the shell moulds
    • Voltage class 250V
    • Good insulating properties through the use of RELICON gel
    • Non-toxic gel
    • Reopenable
    • Easy to install
    • UV-resistant
    • Resistant to ageing
    • Weather-resistant
    • Temperature-resistant from -30°C to 130°C
    • Unlimited storage life
    • Certified according to DIN EN 60998-2-1:2004
    • Incl. connector block
    Show more
    Downloads Datasheet
    Application Relilight gel cable joints are designed for light installations, LED lighting as well. They are tested according to EN 60998-2-1: 2004 and offer IP68 protection class. The moulding shells are also flame retardant. Depending on the connector type, Relilight can be used either for straight-through or as branch joints. They are suitable for jointing on polymeric cables and wires made of PVC, XLPE, PE, EPR etc. The silicone based gel in the Relilight cable joints not only provides excellent insulation but also a simple, effortless installation. Application: In low-voltage electrical networks as straight-through or branch joints, e.g. for outdoor light installations, like garden lightning, underground, submerged, outdoor, indoor and in wiring ducts.
    Colour Black (BK)
    Content Gel shell filled with RELICON gel
    Adapter for strain relief
    Installation instruction
    Connector block 3 x 0,5 mm² to 3 x 1,5 mm²
    Screws
    Material Polyamide 6.6 V0 (PA66V0), Silicone (SI)
    No. of Wires 3
    PART DESCRIPTION Relilight V31.5U1-PA66V0/SI-BK
    Pack Cont. 1Bag
    Package Content packed in box
    Product Family RELICON Relilight V 31,5 U1
    Product Group Straight-through and branch gel cable joints with connectors
    Type Relilight V31.5U1
    Variant Gel
    Voltage range 250V
    Cable Size (max.) 3 x 1.5mm²
    Height (H) 29.5mm
    Length (L) 38mm
    Main Cable min 3 x 0.5mm²
    Width (W) 42.5mm
    CE Certification No
    ELV compliant (Article 4 - 2) YES
    Hazardous Goods No
    Operating Temperature -30 °C to +130 °C
    ROHS compliant Yes
    Self extinguishing Yes
    Shelf Life Unlimited
    Specifications
    Specifications EN 60998-2-1:2004
    Thermal Conductivity (max.) 0.17W/mK
    Thermal Conductivity (min.) 0.17W/mK
    GTIN-13 / EAN 4250596413753
    Packaging 1 - Height (m) 0.025m
    Packaging 1 - Length (m) 0.075m
    Packaging 1 - Qty 1
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.00013m³
    Packaging 1 - Weight (kg) 0.035399kg
    Packaging 1 - Width (m) 0.07m
    Packaging 2 - Height (m) 0.09m
    Packaging 2 - Length (m) 0.175m
    Packaging 2 - Qty 10
    Packaging 2 - Type carton
    Packaging 2 - Volume (m³) 0.0017m³
    Packaging 2 - Weight (kg) 0.424kg
    Packaging 2 - Width (m) 0.105m
