Pre-Insulated Terminals
Art.-No. 911-01045 | F1DMY-PA66/MET-RD |  Details

Quick connect fully insulated 105°C double grip terminal, QDF1-6F.

    Colour Red (RD)
    Description TERMINAL P-I DISC MALE RED 6.35mm
    Material Polyamide 6.6 (PA66), Metal (MET)
    PART DESCRIPTION F1DMY-PA66/MET-RD
    Pack Cont. 100pcs.
    Part No. F1DMY
    Product Family Fully Insulated Male Disconnects
    Product Group Pre-Insulated Terminals
    Type F1DMY
    For AWG 16-22
    Inside Ø (ID) 4.10mm
    Length (L) 22.0mm
    Width (W) 6.40mm
    Wire Size Range (mm²) 0.5-1.5mm²
    GTIN-13 / EAN 6005242013027
