PVC Electrical Insulation Tapes
Art.-No. 911-01109 | HT3-PVC-BK |  Details

    • Extremely flexible, even in cold weather
    • Unaffected by moisture and most chemicals
    • No flagging or deterioration even under temperatures as high as 80 ºC
    Application HT3 is cold and weather resistant electrical tape, coated with an aggressive rubber resin adhesive with good ageing characteristics. Extremely flexible, even in cold weather and unaffected by moisture and most chemicals. No flagging or deterioration even under temperatures as high as 80°C.
    Colour Black (BK)
    Description INSULATION TAPE HELLER .13x19mm x 10m BLACK
    Material Polyvinylchloride (PVC)
    PART DESCRIPTION HT3-PVC-BK
    Pack Cont. 10pcs.
    Part No. HT3BK
    Product Family Hellertape
    Product Group PVC Electrical Insulation Tapes
    Type HT3
    Length (L) 10.0m
    Thickness (T) 0.13mm
    Width (W) 19.0mm
    Adhesion to Backing 1.6N/10 mm
    Breaking Strength 17N/10 mm
    Dielectric Strength 5.5kV/mm
    Elongation at break 160%
    Operating Temperature -20 °C to +80 °C
    GTIN-13 / EAN 6005242023200
