Pre-Insulated Terminals Fully Insulated Male Disconnects
Art.-No. 911-01047 | F3DMY-PA66/MET-YE |  Details

Quick connect fully insulated 105°C double grip terminal, QDF5-6F.

    Colour Yellow (YE)
    Description TERMINAL P-I DISC YELLOW 6.35mm
    Material Polyamide 6.6 (PA66), Metal (MET)
    PART DESCRIPTION F3DMY-PA66/MET-YE
    Pack Cont. 100pcs.
    Part No. F3DMY
    Product Family Fully Insulated Male Disconnects
    Product Group Pre-Insulated Terminals
    Type F3DMY
    For AWG 10-12
    Inside Ø (ID) 6.60mm
    Length (L) 24.5mm
    Wire Size Range (mm²) 4.0-6.0mm²
    GTIN-13 / EAN 6005242013041
