24/11/2024

Cable tie outside serrated, 100.0x2.5mm, ∅1.6-20.0mm, black, 500pcs.
Art.-No. 118-04701 | T18ROS-PA66HS-BK |  Details

Outside serrated OS-Series cable tie with smooth surface to the bundle.

    This product is not available anymore.
    • Outside serrated cable tie with smooth surface to the bundle
    • Tie follows the contours of the cable bundle perfectly
    • Takes up less space due to curved head design
    • Easy insertion combined with high tensile strength
    • PA46 material for higher temperatures up to +195 °C (500 h)
    • PA66V0 cable ties fulfill Limited Fire Hazard requirements
    • Easy application either manually or with a processing tool
    Show more
    Downloads Datasheet e-Learning
    Application OS-Series cable ties are used in many areas where thin-walled or soft insulation wires and cable are being installed, for instance automotive and aircraft industry. OS ties manufactured from PA66V0 material are suitable for applications where safety regulations require reduction of smoke and dangerous gases.
    Colour Black (BK)
    Identification Plate Position none
    Material Polyamide 6.6, heat stabilised (PA66HS)
    PART DESCRIPTION T18ROS-PA66HS-BK
    Pack Cont. 500pcs.
    Package Content packed in bag
    Part No. T18ROSHSBK
    Product Family OS-Series
    Product Group Cable ties for thin-walled bundles
    Releasable Closure (Yes/No) No
    Tie Closure plastic pawl
    Type T18ROS
    Variant Outside Serrated
    Bundle Diameter max (metric) 20.0mm
    Bundle ∅ min. 1.6mm
    Height (H) 1.0mm
    Length (L) 100.0mm
    Min.Tensile Strength 80N
    Thickness (T) 1.0mm
    Width (W) 2.5mm
    CE Certification No
    CSA Certified No
    ELV compliant (Article 4 - 2) YES
    Flammability UL 94 V2
    Halogen-free Yes
    Hazardous Goods No
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised No
    GTIN-13 / EAN 5022660320255
    Packaging 1 - Height (m) 0.04m
    Packaging 1 - Length (m) 0.28m
    Packaging 1 - Qty 500
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.0023m³
    Packaging 1 - Weight (kg) 0.1399kg
    Packaging 1 - Width (m) 0.205m
    Packaging 3 - Height (m) 0.192m
    Packaging 3 - Length (m) 0.586m
    Packaging 3 - Qty 20000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0439m³
    Packaging 3 - Weight (kg) 6.00204kg
    Packaging 3 - Width (m) 0.39m
    Packaging 4 - Height (m) 1.164m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 400000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.117m³
    Packaging 4 - Weight (kg) 141.04kg
    Packaging 4 - Width (m) 0.8m
    UNSPSC Key 39121703
